MANOMETER DN63 VERTICAL 0 - 400 BAR - 1/4"
Article code:
10582
OEM:
9990000005055
Tax rate
22 %
Price without VAT:
9,84 EUR
Price with VAT:
12,00 EUR
Ref:
22
| Technical data | |
| Accuracy: | 1.6% |
| Supplier: | Spain |
| Temperature range: | from -10 to +60 |
| Return or exchange: | 14 days |
| Manometer scale: | 0 - 400 bar |
| Units on scale: | per 10 bar |
| Connection thread: | 1/4" |
| Material: | Case: stainless steel 304, Ring: stainless steel 304, Window: polycarbonate (glass), Connection: brass |
Description:
Pressure gauges are used for measuring oil pressure in hydraulic systems. Since vibrations and pulsating loads are present in fluids, we offer glycerin-filled pressure gauges.
Accuracy class (according to EN 837)
Note: Some pressure gauges are supplied with a sealed vent plug due to transport. For proper operation, it may be necessary to puncture or cut the top plug before use in accordance with the manufacturer’s instructions. This allows pressure equalization inside the housing and ensures accurate measurement.
