MANOMETER DN100 REAR 0 - 400 BAR - 1/2"
Article code:
12224
OEM:
9990000067510
Tax rate
22 %
Price without VAT:
19,67 EUR
Price with VAT:
24,00 EUR
Ref:
3
| Technical data | |
| Accuracy: | 1.6% |
| Supplier: | Spain |
| Temperature range: | from -10 to +60 |
| Return or exchange: | 14 days |
| Manometer scale: | 0 - 250 bar |
| Units on scale: | per 5 bar |
| Connection thread: | 1/2" |
| Material: | Case: stainless steel 304, Ring: stainless steel 304, Window: polycarbonate (glass), Connection: brass |
Description
The DN100 REAR pressure gauge is designed for measuring pressure in hydraulic, pneumatic, and other pressurized systems. Due to the larger diameter of the measuring scale, it provides excellent visibility and accurate reading of measured values even from a greater distance.
The rear connection allows installation in control panels, control cabinets, and other built-in applications. The pressure gauge is used in hydraulic power units, industrial equipment, compressor systems, process engineering, and other equipment where continuous monitoring of operating pressure is required.
Accuracy class (according to EN 837)
