MOUNTING SET FOR HYDRAULIC ACCUMULATOR FOR TRACTOR FRONT HYDRAULICS
| Technical information | |
|
Supplier: |
Italy |
|
Return or exchange: |
14 days |
|
Warranty |
6 months |
|
Weight of the kit: |
5,5 kg |
|
Model: |
H700R |
|
Max. flow: |
40 L/min |
|
Capacity: |
0,75 L |
|
Pre-charge: |
160 bar |
|
Charging: |
Nitrogen (N₂) - 5/8” UNF |
|
Shut-off valve: |
3/8" |
Description:
The hydraulic accumulator is an important component of many hydraulic systems, designed to store energy in the form of compressed hydraulic fluid (oil). It enables damping of pressure shocks, provides volume compensation, and facilitates additional oil flow during rapid load changes, helping to maintain constant system pressure.
Advantages of using a hydraulic accumulator:
- reduces the load on components within the hydraulic system (hydraulic pump, hydraulic valve, etc.),
- extends the service life of hydraulic components,
- absorbs pressure shocks and vibrations,
- improves the efficiency and stability of the hydraulic system.
The set includes:
- hydraulic accumulator with a capacity of 0,75 L,
- shut-off valve with 3/8" thread,
- hydraulic hose with eye fitting.
This hydraulic accumulator set is recommended for an enhanced user experience with our tractor's front hydraulics. The oil flow is blocked when the shut-off valve lever is positioned at 90° to the valve, and is free when the lever is parallel to the valve and oil line.
